TECNOLAN密封
GHM （GUARNITEC - 意大利液路坚TECNOTEX GHM）
所属分类： TECNOLAN密封
产品简介：TPM组合密封是一种双作用的密封和导向元件，由一个弹体密封圈、两个挡圈和两个导向环组成。密封圈在静态和动态都能起良好密封作用，而挡圈可防止橡胶密封圈被挤入密封间隙，导向环的作用是使活塞在缸筒内导向并吸收径向力。这种设计提供了一种紧凑的密封与导向的组合，可用于开放式或封闭式安装沟槽。优点-密封效果好，也适用于支承缸；可安装在封闭式沟槽中，能降低加工成本；经济型的“密封加导向”解决方案；开切口的挡圈和导向环安装方便。技术数据工况技术条件压力:≤ 40 MPa速度:≤ 0.5 m/s温度: -30℃至 100℃材料:矿物液压油，抗燃液压油，HFA，HFB，HFC( 40℃)材料TPM组合密封用于下列材料组合:密封圈:丁晴橡胶，邵氏A 80挡圈:聚酯弹性体导向环: POM
产品详情
GHM （GUARNITEC - 意大利液路坚TECNOTEX GHM）
| 型号 | 规格 |
| GHM 047070 | 12*18.6*3.8 |
| GHM 051074 | 13*19.6*3.8 |
| GHM 059082 | 15*21.6*3.8 |
| GHM 062087 | 16*22.6*3.8 |
| GHM 062094 | 16*24.6*5.3 |
| GHM 066090 | 17*23.6*3.8 |
| GHM 070094 | 18*24.6*3.8 |
| GHM 074110 | 19*28.6*5.3 |
| GHM 078110 | 20*28.6*5.3 |
| GHM 086118 | 22*30.6*5.3 |
| GHM 094125 | 24*32.6*5.3 |
| GHM 098129 | 25*33.6*5.3 |
| GHM 102133 | 26*34.6*5.3 |
| GHM 106137 | 27*35.6*5.3 |
| GHM 110141 | 28*36.6*5.3 |
| GHM 118149 | 30*38.6*5.3 |
| GHM 125157 | 32*40.6*5.3 |
| GHM 129161 | 33*41.6*5.3 |
| GHM 137169 | 35*43.6*5.3 |
| GHM 141173 | 36*44.6*5.3 |
| GHM 149181 | 38*46.6*5.3 |
| GHM 157188 | 40*48.6*5.3 |
| GHM 165196 | 42*50.6*5.3 |
| GHM 177208 | 45*53.6*5.3 |
| GHM 177216 | 45*55.6*5.3 |
| GHM 181212 | 46*54.6*5.3 |
| GHM 188220 | 48*56.6*5.3 |
| GHM 196228 | 50*58.6*5.3 |
| GHM 196236 | 50*60.6*5.3 |
| GHM 208240 | 53*61.6*5.3 |
| GHM 216248 | 55*63.6*5.3 |
| GHM 216255 | 55*65.6*5.3 |
| GHM 220251 | 56*64.6*5.3 |
| GHM 220259 | 56*66.6*5.3 |
| GHM 236267 | 60*68.6*5.3 |
| GHM 236275 | 60*70.6*5.3 |
| GHM 248279 | 63*71.6*5.3 |
| GHM 248287 | 63*73.6*5.3 |
| GHM 255287 | 65*73.6*5.3 |
| GHM 255295 | 65*75.6*5.3 |
| GHM 275307 | 70*78.6*5.3 |
| GHM 275314 | 70*80.6*5.3 |
| GHM 275322 | 70*82.6*7.1 |
| GHM 295326 | 75*83.6*5.3 |
| GHM 295345 | 75*87.2*7.1 |
| GHM 301348 | 76.5*88.7*7.1 |
| GHM 314346 | 80*88.6*5.3 |
| GHM 314362 | 80*92.2*7.1 |
| GHM 334366 | 85*93.6*5.3 |
| GHM 334381 | 85*97.2*7.1 |
| GHM 354385 | 90*98.6*5.3 |
| GHM 354401 | 90*102.2*7.1 |
| GHM 374421 | 95*107.2*7.1 |
| GHM 380437 | 97*111*7.1 |
| GHM 393425 | 100*108.6*5.3 |
| GHM 393440 | 100*112.2*7.1 |
| GHM 413460 | 105*117.2*7.1 |
| GHM 433480 | 110*122.2*7.1 |
| GHM 452500 | 115*127.2*7.1 |
| GHM 472504 | 120*128.6*5.3 |
| GHM 472519 | 120*132.2*7.1 |
| GHM 492539 | 125*137.2*7.1 |
| GHM 492551 | 125*140.2*10.1 |
| GHM 511559 | 130*142.2*7.1 |
| GHM 531578 | 135*147.2*7.1 |
| GHM 551598 | 140*152.2*7.1 |
| GHM 551610 | 140*155.2*10.1 |
| GHM 570618 | 145*157.2*7.1 |
| GHM 570629 | 145*160.6*9 |
| GHM 590622 | 150*158.6*5.3 |
| GHM 590637 | 150*162.2*7.1 |
| GHM 590649 | 150*165.2*10.1 |
| GHM 629688 | 160*175.2*10.1 |
| GHM 669728 | 170*185.2*10.1 |
| GHM 688748 | 175*190*7 |
| GHM 708767 | 180*195.2*10.1 |
| GHM 708787 | 180*200.2*10.2 |
| GHM 748826 | 190*210*10.2 |
| GHM 787847 | 200*215*10 |
| GHM 826866 | 210*220*10 |
| GHM 787866 | 200*220.2*10.2 |
| GHM 826905 | 210*230*10.2 |
| GHM 866944 | 220*240*10.2 |
| GHM 886964 | 225*245*10.2 |
| GHM 905984 | 230*250*10.2 |
| GHM 9441024 | 240*260*10.2 |
| GHM 9841062 | 250*270*10.2 |
| GHM 10241102 | 260*280*10.2 |
| GHM 10621141 | 270*290*10.2 |
| GHM 11021181 | 280*300*10.2 |
| GHM 11811259 | 300*320*10.2 |
| GHM 12201299 | 310*330*10.2 |
| GHM 12591338 | 320*340*10.2 |
| GHM 13381417 | 340*360*10.2 |
| GHM 14171496 | 360*380*10.2 |
| GHM 14961614 | 380*410*25 |
| GHM 15741653 | 400*420*10.2 |
| GHM 16531732 | 420*440*12.2 |
| GHM 17321843 | 440*470*15.2 |
| GHM 17501900 | 444.5*482.6*15.9 |
| GHM 17711843 | 450*470*10.2 |
| GHM 19682047 | 500*520*10.2 |
| GHM 19882066 | 505*525*10.2 |
| GHM 20862165 | 530*550*10.2 |
| GHM 22432323 | 570*590*10.2 |
| GHM 23622440 | 600*620*10.2 |
| GHM 25192598 | 640*660*10.2 |
| GHM 25582638 | 650*670*10.2 |
